应用与简单介绍/Brief Introduction：

远程服务器组为10-20ml服食液液滴灌装仪器仪器线产生线中的重要系统。是由洗瓶、烤干一起化机和灌装仪器仪器线塑封一起化机所组建，能主动成功完成服食液瓶的洗瓶、烤干、灌装仪器仪器线和塑封等小动作，是服食液产生企业更非常理想的模块化系统，是复合GMP的标准。It’s a major equipment in production line for oral filling, it main used in filling, capping placing and sealing of 10-20ml bottles. Tracking filling, cap automatically conveying by electromagnetic oscillator, automatic sealing , no bottle no filling. Filling and sealing integrated in one machine, advanced design, compact structure and completely comply with requirement of GMP

作用/Characteristic：

◆装量精确性，制止渗漏。装罐精密度较高。High filling accuracy.◆直流变频无及调速器，的生孩子效率可以调整，待选择的不同的的生孩子效率。Frequency control, production speed is adjustable, you can choose a different production rate.◆全部机械元器件均所采用进口商出名店牌。All electrical components are imported famous brands.◆智能彰显计数器效果。Automatically countting function.◆操纵用岛国三菱PLCPLC，抗影响，工做不稳定性。Controlled by Mitsubishi PLC◆性能方面稳定性高，维持清洗简便。Stable performance, easy maintenance.◆整个机械外表通常看上去运用SUS304不锈碳钢作、与原辅材料接触到部份运用316L不锈钢管材质的。整个机械是按GMP标准设计的。Outer material is 304 stainless steel, and the material of filling part is 316L stainless steel. The machine is completely designed according to GMP requirements.

技术应用性能/technical parameters：

适用于产品规格/Bottle size	10-20ml
生产方式能力素质/Capacity	60-90瓶/min/60-90bottles/min
烘干功能温度表/Dryer tempreture	100-300°
造纸废水处理流水量/Water wastage	0.5m3/h
再生水耗量/Purifying water consumption	0.3m3/h
装量精密度较/Filling precision	≤1%
电源开关/Voltage	380V/50Hz
工率/Power	33KW
生孩子线总长/Dimension	3500×1500×1600mm
