借款用途与筒介/Brief Introduction：

什么是服务器适合特异三通接头装灌机 生产线机 阀，适合于水剂和膏霜类物品的装灌机 生产线机 ，特点对高粘性材料（如浓酱、朝天椒酱、番茄酱、种衣剂、微乳剂、浮悬剂等）的使用效果很显眼，且高精度就越高。什么是服务器适合PLC可程序编程管理，搭配65英寸触模屏人与机器软件界面系统，实施主动进瓶，主动装灌机 生产线机 ，主动出瓶，电子产品，油路分配器元构件均适合國際企业，保持了漂亮的品质和更久比较稳定的能力。本机 机构简略，工作便于，是我国国内很好的针对性高粘性材料的装灌机 生产线机 机 。什么是服务器有了避免 漏滴与磨砂工艺的装灌机 生产线机 闷头，保持装灌机 生产线机 结束之后后无漏滴，无磨砂工艺。Filling valve, the machine USES special tee is suitable for the filling agent and cream products, especially for high viscosity material (such as thick sauce, chili sauce, tomato sauce, indicated, micro emulsion, suspending agent, etc.) of the effect is obvious, and high precision. The machine USES PLC programmable control, with 6 inch touch screen man-machine interface system, implements the automatic into the bottle, automatic filling, automatic bottle, electric, pneumatic components adopt international brand, to ensure that the performance of the outstanding quality and lasting stability. This equipment has simple structure, convenient operation, is the ideal filling equipment for high viscosity material. The machine is equipped with prevent drip with wire filling cocks, ensure filling after the completion of a drip-tight, no drawing.

的特点/Characteristic：

◆掌控系统软件的——适用三凌PLC掌控系统软件的，灌装线分子量随机函数上下调整。Control system adopt mitsubishi PLC control system, filling dose random tweaks◆运营接口——6寸大彩屏手触式运营接口，抽象化简单的、卫生可以信赖Interface - 6 inches color hand touch interface operation, intuitive and simple, safe and reliable◆功效改进措施——切料有防渗漏系统设计，可表明介质特征参数要具备下潜灌装生产线功效。（此功效能否应用）Improvements - blanking drip tight device, according to the material properties have diving filling function. (this function can be chosen)◆电器开关电子器件——均用于国际性有时尚牌子牌，确认机械设备的应急稳定可靠、最准确高；Electrical components adopt international famous brand, to ensure the equipment safe and reliable, high accuracy;◆厂家核心核心部件——系统核心核心部件均利用质优304不锈铝生产制作,予以必须 接触到原辅材料会利用316L另计算用。Mechanical parts, machine parts are made of high quality 304 stainless steel material can be used if necessary contact 316 l in extra costs.◆筛选器检侧——实时公交筛选器，对岗位产油量主观反映了。Counting test, real-time, intuitive reflect the yield of work.◆灌装线监测——无瓶不灌、瓶数不高不灌Bottle filling test - no bottle no filling, not enough◆维修保养具体情况——远程服务器符合的标准GMP的标准，可快些拆迁、拆洗维修保养。Maintenance - the machine is in line with the GMP requirements, easy disassembly, cleaning maintenance.◆替换尺寸型号——换成包装尺寸型号时，只需要简短变动，简单搞好。Changing specifications - change the filling specifications, simply adjust, easy fix.◆低能耗标准性能——标准性能了低能耗体系结构，使机子的运行工作环境更为卫生防疫卫生防疫。（此低能耗标准性能就能够选择）Environmental protection configuration, configuration framework of environmental protection, make the operation of the machine environment more clean sanitation. (the environmental protection configuration can be selected)

系统运作/technical parameters：

分装头数The number of filling head	8头（可以4、6、8、10、1▨6个灌装设备头）8 head (optional 4, 6, ಌ8, 10, 12 filling head)
选用瓶径 Applicable bottles Drive	Ф33-Ф100 mm
计量检测误差measure precision	±1%
罐装发热量Canned capacity	150-1000ml
分娩技能Production Capacity	2400-4000瓶/小时候2400-4000   bottles per hour
气源压力bleed pressure	0.7-0.9mpa
电    源Power Supply	380 伏/50 HZ
总 功 率The total power	0.5 kw
外形尺寸 boundary dimension	6000×850×1800 mm
重    量Weight	500kg
