功用与概况/Brief Introduction：

机器是替代内服液夹层可瓶子的新好产品，彻底消除搞定了常有内服液夹层可瓶子的不合格品治疗效果。此类灌封机用到的可瓶子，虽然不要洗瓶机、烘干设备机，更不要清洁消毒，行进行灌封。此机全自己理瓶、进瓶、分装，分装量平稳性高，无漏滴，无瓶不分装。上盖、封膜率大约100%。此机方法最先进，体型小、工作平稳性高、嗓声低，的操作维护、洁净有利等特殊性，可以达到GMP细则。This machine is a new product instead of oral liquid bottles, thoroughly solved before the adverse effect of oral liquid glass bottle. The used plastic bottles, filling and sealing machine not only don't need to bottle washer, dryer, more don't need disinfection, can be directly potting. The machine is fully automatic unscramble bottle, bottle feeding, filling, filling volume stability, no LouDi, no bottle no filling. Cover and sealing rate can reach 100%. This machine technology is advanced, small volume, stable running, low noise, convenient operation and maintenance, cleaning, etc, in full compliance with GMP standard.注：本款式有底速和绕城高速两大类生产产量供您选择。Note: this model has two kinds of low speed and high-speed production for your choice.

优点 Characteristic

◆机器应用到多种多样易折瓶内服液量值溯源包装和密封。The machine is suitable for all kinds of folding bottles of oral liquid filling and sealing of measurement.◆大多数物品组件均应用顶级该品牌。All electrical components adopt famous brand◆远程服务器控制可以直观便利，无瓶不装灌，计算*。It has intuitive and convenient operation, no bottle no filling, measuring precision.◆易折塑料制品瓶灌封机的主耍组成与原里Easy to fold the main structure and principle of plastic bottle filling and sealing machine◆NFGFY型口服方式液易折塑料制品瓶灌封机重点理瓶器、理盖器、主机械厂传动体系、发送到带摩擦送成瓶置、空罐检漏安装、灌装设备医院、清除安装、热溶封医院、气动平衡机械厂手指头夹瓶医院、交流松下伺服电机的电机的摩擦上瓶医院与出瓶医院等组合成。Type NFGFY oral liquid is easy to fold the plastic bottle filling and sealing machine main GaiQi bottle opener, and the main transmission system, the synchronous belt clearance to send bottle device, empty bottle leak detection device, filling body, eliminating device, hot melt sealing mechanism, pneumatic mechanical fingers bottle gap on the bottle structure, servo motor and a bottle of institutions, etc.◆电脑采用的服用液易折塑料件瓶、盖都是定洁净间区生产的的，是指泡脚药材准许证，所以咧瓶身与底盖经传递信息和"去劳务外包"后可可以流入灌封间。完成理盖器、理瓶器的自动化方向分类整理，去除返向底盖及瓶身底口朝下的瓶，使方向后的包材喂料有要求地流入传输行列中。Machine using oral liquid is easy to fold the plastic bottles, cover a certain production of clean area, should have the medicine packaging material license, so the bottle and the bottom cover after transfer and "outsourcing" can go directly into the potting. By Richard GaiQi, automatic directional arrangement of bottle opener, eliminate reverse bottom cover and the bottom of the bottle mouth bottle at the bottom, after making the orientation of packaging material feeding regularly into orbit. ◆定向就业后服用液易折塑料管瓶在传输发展轨道总排名Directional oral liquid after folding plastic bottles in conveying rail out easily

新技术因素technical parameters：

型号model	NLGFY-40	NLGFY-80
装量标准The load range	5-100ML
生产能力production capacity	20-40瓶/分	50-80瓶/分
封口处率Hot sealing intensity	》99%
装量差值The load error	《1.5%
已经破损率damage rate	《1.0%
输出功率power	2KW	3KW
24v电源Power Supply	380V 50Hz/220V 50Hz
外形尺寸boundary dimension	2700*1100*1900mm	3000*1480*1900mm
质量 Weight	700Kg	800Kg
