使用与介简/Brief Introduction：

本的手动生产线由全手动理瓶机、全手动调频式三头数片（粒）机、手动调频式塞纸旋盖机、磁感测器感测器铝箔纸封好处机、落地式标贴纸汽轮发电机组成。适用以于药业、产品、日用品等业内的颗粒剂、丸剂、口服胶囊还有其他异形图片片的计数器分装、塞纸、旋盖、封好处、标贴纸等设计全期间。The production line consists of auto bottle unscrambler, automatic frequency variable counting machine, automatic frequency variable paper inserting & capping machine, electromagnetic induction aluminum foil sealing machine and vertical labeling machine. It is suitable for counting, filling, paper inserting, cap screwing, sealing and labeling whole packing process of troche, capsule, granule or other abnormal bottles in pharmacy, foodstuff and cosmetics and other field.

亮点/Characteristic：

◆自动式理瓶机，理瓶流程全通过机戒性动作，不能不值班人员安装监控，又快又好省劲。Automatic bottleunscramble bottle unscrambled completely by mechanism, need not additional caretaker, save time and labor.◆变频器柜筛动式数片机：噪声小、落片稳定性高、计数法正规、速度快快与慢经由变频器柜能否调整，并装否有瓶进行落片的光控安全装置.Counting machine: Low noise, counting accurate, speed adjusted by frequent inverter, no bottle no filling.◆定频式塞纸旋盖机：设计原因发达，框架适当合理紧凑型轿车，全自己送纸、美工刀弄断 ，强度速率进行定频变频调速，无瓶全自己宕机。Paper inserting & capping machine: Advanced .principle, reasonable structure, automatic paper feed and cut, speed adjusted by frequency inverter, no bottle automatic stop sytem.◆铝泊粘口机：配用无铝泊电脑自动移除平衡装置，进程在需要规模内可以调整Aluminum foil sealing machine: Automatically eliminate function for cap that has no aluminum foil, Speed can be adjusted in certain scope.◆透明不干胶贴标签机：都具有无瓶时系统自动化进行出标，系统自动化打批号效果。 Labeling machine: no bottle no label feeding, automatic code typing.

技术应用规格/ Technical Parameters：

可用于规格型号Bottle Range	15-500ml
生產效率 Productivity	30-60瓶/分 30-60bottles/min
电源线Power Supply	380V/50Hz
最大功率 Total Power	4.5 kw
生产的线总长Dimension	8000*900*1700mm
